SHINE PRO
SHINE PRO Small
AEF3S03/AEF3S04 Low Power Square Projector
Modern clarity defines SHINE PRO Small. The seamless all-glass façade aligns with contemporary architectural trends while concealing a modular internal platform. Optimized thermal management extends operational life, and multi-directional aiming capability supports vertical, horizontal, or compound adjustment. Available in varied outputs and beam distributions for flexible exterior articulation.
Features
Double protection, built-in anti-glare structure + special glass surface
Built-in anti-glare module maximizes to reducte the glare damage, the surface of the special glass to ensure light transmittance rate at the same time and eliminate the surface of the stray light
Ultra-narrow beam angle 4°
Multiple beam angle options, 4° extra-narrow beam angle
Simultaneous support for the adjustment of three axes
Single light supports 0-355° horizontal, -30°-150° vertical and 0-90° head adjustment.
Specifications
Model | Power (W) | LEDs (quantity) | Max Lumens (lm) | Control Systems | Beam | CCT | Finish |
AEF3S03 | 08 08W(Max) | 3 | 526 | EL ON-OFF ML DMX512 Dimming | V 4° | 27 2700K 30 3000K 40 4000K | BK Black |
Model | Power (W) | LEDs (quantity) | Max Lumens (lm) | Control Systems | Beam | CCT | Finish |
AEF3S04 | 10 10W(Max) | 4 | 604 | EL ON-OFF 220V AC Power Supply ML DMX512 Dimming | S 6° 1 13° 2 20° 3 30° J 8° x 27° | 27 2700K 30 3000K 40 4000K | BK Black |
Model | Power (W) | LEDs (quantity) | Max Lumens (lm) | Control Systems | Beam | CCT | Finish |
AEF3S04 | 10 10W(Max) | 4 | 305 | ML DMX512 Dimming 220V AC Power Supply | 1 19° 2 29° 3 37° 5 53° F 23°x 36° | F3 RGBW(3000K) F4 RGBW(4000K) F6 RGBW(5700K) | BK Black |
Example: AEF3S04-10ML1F30BK
