VOLTA

VOLTA Square Adjustable 2/3

ADDT25/ADDT35 2/3" Adjustable Downlight
Adaptive square precision defines VOLTA Square Adjustable 2/3. A refined optical system ensures accurate beam definition with advanced glare suppression, while the sealed chamber protects against humidity. Replaceable reflectors provide enhanced on‑site flexibility.

Features

High thermal performance

High thermal performance

Convection cooling + Enclosed chimney cooling to enhance thermal performance
IP44 sealed light source chamber design

IP44 sealed light source chamber design

Ensures stable performance in humid environment
No light spot spill out (right VOLTA)

No light spot spill out (right VOLTA)

Actual light effect with clean, soft spot and no stray light
Adjustment without light leakage (right VOLTA)

Adjustment without light leakage (right VOLTA)

Combination of light perfromance and anti-glare design, no stray light throughout the process of tilting angle

Specifications

Model

Size

Trim

LED

Driver

Beam

CCT

Reflector

Finish

ADDT

2 2”

5 Square Trim

LD08  LED 8W

E  On-Off

D  0-10V Dimming

A  DALI

N  No Driver

1     15°

2     24°

3     36°

5     50°

27  2700K

30  3000K

35  3500K

40  4000K

50  5000K

B  Black

S  Specular

WT White

BK  Black

Model

Size

Trim

LED

Driver

Beam

CCT

Reflector

Finish

ADDT

3 3”

5 Square Trim

LD08  LED 8W

E  On-Off

D  0-10V Dimming

S     8°

27  2700K

30  3000K

35  3500K

40  4000K

50  5000K

B  Black

S  Specular

WT White

BK  Black

Model

Size

Trim

LED

Driver

Beam

CCT

Reflector

Finish

ADDT

3 3”

5 Square Trim

LM07  COB 7W

LM10  COB 10W

LM13  COB 13W


E  On-Off

D  0-10V Dimming

1     15°

2     24°

3     36°

5     50°

27  2700K

30  3000K

35  3500K

40  4000K

50  5000K

B  Black

S  Specular

WT White

BK  Black

Model

Size

Trim

LED

Driver

Beam

CCT

Reflector

Finish

ADDT

3 3”

5 Square Trim

LM13  COB 13W


A  DALI

N  No Driver

1     15°

2     24°

3     36°

5     50°

27  2700K

30  3000K

35  3500K

40  4000K

50  5000K

B  Black

S  Specular

WT White

BK  Black

Example:ADDT35-LM13E230SWT
