LIGNE PRO

LIGNE PRO Recessed

ALLAR5 Recessed Linear Downlight
Compact yet highly configurable, LIGNE PRO Recessed Downlight reinterprets the traditional downlight through a linear lens. Offered in multiple LED configurations with varied output and length options, it provides adaptable beam control for layered lighting strategies. Whether establishing spatial hierarchy or serving as primary illumination, LIGNE PRO delivers disciplined performance from a refined recessed profile—an architectural alternative to conventional point-source downlights.

Features

Downlight 15°, 28°, 36° beam angles available

Downlight 15°, 28°, 36° beam angles available

Can create a layered sense of space and take into account the application of basic lighting, can completely replace the downlight to use.

Specifications

Model

LED Power

Driver

CCT

 Beam

Reflector

Finish

ALLAR5

Linear Downlights A series

Recessed mounting

LD02  2W

E  On-Off



27  2700K

30  3000K

40  4000K

1  15°

2  28°

3  36°

B   Black

WT White

Model

LED Power

Driver

CCT

 Beam

Reflector

Finish

ALLAR5

Linear Downlights A series

Recessed mounting

LD08  8W

E  On-Off

D  0-10V Dimming



27  2700K

30  3000K

40  4000K

1  15°

2  28°

3  36°

B   Black

WT White

Model

LED Power

Driver

CCT

 Beam

Reflector

Finish

ALLAR5

Linear Downlights A series

Recessed mounting

LD16  16W

E  On-Off

D  0-10V Dimming



27  2700K

30  3000K

40  4000K

1  15°

2  26°

3  36°

B   Black

WT  White

Model

LED Power

Driver

CCT

 Beam

Reflector

Finish

ALLAR5

Linear Downlights A series

Recessed mounting

LD32  32W

E  On-Off

D  0-10V Dimming



27  2700K

30  3000K

40  4000K

1  15°

2  26°

3  36°

B   Black

WT  White

Example: ALLAR5-LD32E271BWT
